From 1995 to 2005, the Michigan plant produced the 3.8-liter General Motors L36 engine, which was fitted to well-known vehicles like the Pontiac Bonneville, Buick Regal, and Chevrolet Impala. This engine was available in a compressor version with the index L67, which produced 240 horsepower and 380 Nm.
Buick V6 engine family: L32, L36, L67.
Specifications
| Production years | 1995 – 2005 |
| Displacement, cc | 3791 |
| Fuel system | distributed injection |
| Power output, hp | 195 – 205 |
| Torque output, Nm | 312 |
| Cylinder block | cast iron V6 |
| Block head | cast iron 12v |
| Cylinder bore, mm | 97 |
| Piston stroke, mm | 86 |
| Compression ratio | 9.4 |
| Features | OHV |
| Hydraulic lifters | yes |
| Timing drive | chain |
| Phase regulator | no |
| Turbocharging | no |
| Recommended engine oil | 5W-30 |
| Engine oil capacity, liter | 4.3 |
| Fuel type | petrol |
| Euro standards | EURO 2/3 |
| Fuel consumption, L/100 km (for Pontiac Bonneville 2004) — city — highway — combined |
12.4 7.8 10.2 |
| Engine lifespan, km | ~400 000 |
| Weight, kg | 178 |
The engine was installed on:
- Buick LeSabre 7 (H-body) in 1995 – 1999; LeSabre 8 (GMX220) in 1999 – 2005;
- Buick Park Avenue 1 (C-body) in 1995 – 1996; Park Avenue 2 (G-body) in 1996 – 2005;
- Buick Regal 4 (W-body) in 1996 – 2004;
- Buick Riviera 8 (G-body) in 1995 – 1997;
- Chevrolet Camaro 4 (F-body) in 1995 – 2002;
- Chevrolet Impala 8 (GMX210) in 1999 – 2005;
- Chevrolet Lumina 2 (W-body) in 1997 – 1999;
- Chevrolet Monte Carlo 5 (W-body) in 1997 – 1999; Monte Carlo 6 (GMX230) in 1999 – 2005;
- Oldsmobile Intrigue 1 (GMX170) in 1997 – 1999;
- Oldsmobile Regency 1 (H-body) in 1996 – 1999;
- Pontiac Bonneville 9 (H-body) in 1995 – 1999; Bonneville 10 (GMX310) in 1999 – 2005;
- Pontiac Firebird 4 (F-body) in 1995 – 2002;
- Pontiac Grand Prix 7 (W-body) in 1996 – 2003.
Disadvantages of the GM L36 engine
First of all, this series of engines is well known for their frequent coolant leaks.
A leaky gasket beneath the intake manifold is typically the cause of the leak.
Additionally, the plastic pipe beneath the generator bursts and is swapped out for a metal one.
Additionally, a crankshaft position sensor, coils, and spark plugs have limited resources.
These engines were the subject of a recall campaign in 2009 because of the fire risk.
