Overview & Design Features
The Haval 4G63S4T is a significant turbocharged inline-four gasoline engine developed and manufactured by Great Wall Motors (GWM), primarily for its Haval SUV brand. With a displacement of 1997 cubic centimeters (2.0 liters), this engine represents GWM’s commitment to delivering robust and cost-effective powertrains. Its designation, “4G63,” pays homage to its Mitsubishi heritage, as it is a modernized derivative of the renowned Mitsubishi 4G63 engine platform, which has a long history of reliability and performance across various automotive applications. GWM’s adaptation of this platform allowed for quick development and deployment of a proven engine architecture, tailored to meet the demands of the Chinese and export markets for SUVs and light commercial vehicles.
Engineered for durability and efficiency, the 4G63S4T features a sturdy cast-iron cylinder block, which provides excellent structural rigidity and thermal stability, crucial for turbocharged applications. The cylinder head is constructed from an aluminum alloy, optimizing weight and heat dissipation. It utilizes a Double Overhead Camshaft (DOHC) design with 16 valves (four per cylinder) and incorporates Variable Valve Timing (VVT) on the intake side to enhance combustion efficiency, broaden the torque curve, and improve fuel economy. Fuel delivery is managed by a Multi-Port Fuel Injection (MPFI) system, precisely atomizing fuel into the intake manifold before combustion. A single turbocharger, often from a reputable supplier, provides forced induction, significantly boosting power and torque output over naturally aspirated counterparts, while an intercooler reduces intake air temperature for increased charge density.
This engine variant saw widespread application across various Haval and Great Wall Motors models. It was notably deployed in the Haval H5, particularly in its 2.0T guise, and became a popular choice for the Haval H6, one of China’s best-selling SUVs. Other vehicles that utilized the 4G63S4T include earlier generations of the Great Wall CUV H3 and H5, and certain trims of the Great Wall Wingle pickup trucks. Its production run spans approximately from the early 2010s through the mid-2010s, serving as a workhorse engine before the introduction of more advanced, proprietary GWM engines.
Technical Specifications
| Displacement | 1997 cc |
| Max Power | 190 hp (140 kW) @ 5200 RPM |
| Max Torque | 250 Nm (25.5 kg*m) @ 2400-4800 RPM |
| Fuel Type | Gasoline (RON 92 or higher recommended) |
| Fuel Consumption (combined) | Refer to manufacturer’s technical documentation (approx. 8.5-9.5 l/100 km for SUVs) |
| Engine Type | Inline 4, DOHC, Turbocharged, Intercooled |
| Compression Ratio | 9.3:1 |
| Cylinder Bore | 85 mm |
| Piston Stroke | 88 mm |
| Valvetrain | DOHC 16-valve with VVT |
| Valves per Cylinder | 4 |
| Additional Info | Multi-Port Fuel Injection (MPFI), Timing Belt driven camshafts, Liquid-cooled |
Common Problems & Reliability
The Haval 4G63S4T engine, while generally robust, exhibits a few common issues, typical for its design and era. A primary concern for owners is the timing belt system. Unlike modern chain-driven setups, the 4G63S4T relies on a rubber timing belt for camshaft synchronization. Failure to adhere to the manufacturer’s recommended replacement interval (typically every 90,000-100,000 km) can lead to catastrophic engine damage due to piston-to-valve contact. Another area of attention is the turbocharger assembly. Over time, particularly in units with inconsistent oil changes or aggressive driving styles, the turbocharger bearings can wear, leading to excessive oil consumption, smoking exhaust, or reduced boost pressure. Lastly, issues with the ignition system components, specifically spark plugs and ignition coils, can manifest as misfires, rough idling, or a reduction in power. These components have a finite lifespan and are susceptible to degradation, especially if exposed to poor fuel quality or extended service intervals.
Under conditions of diligent maintenance and proper care, the Haval 4G63S4T engine is capable of achieving a realistic service life of approximately 250,000 to 300,000 kilometers (155,000 to 185,000 miles) before requiring a major overhaul.
Maintenance Tips & Service Schedule
Maintaining the Haval 4G63S4T correctly is paramount for its longevity and optimal performance. Regular engine oil and filter changes are critical; synthetic or semi-synthetic engine oil with a viscosity rating of 5W-30 or 5W-40, conforming to API SN/SM or ACEA A3/B4 standards, is recommended. These changes should occur every 7,500 to 10,000 kilometers, or every 6-12 months, whichever comes first, especially for turbocharged engines that generate higher heat. Spark plugs should be inspected and replaced every 30,000 to 40,000 kilometers to ensure efficient combustion and prevent misfires.
The timing belt, including idlers and tensioners, must be replaced strictly according to the manufacturer’s specified interval, typically every 90,000 to 100,000 kilometers or every 6 years. It is highly advisable to replace the water pump simultaneously, as its failure can necessitate another costly timing belt service. The engine coolant should be flushed and refilled every 2-3 years or 60,000 kilometers with an appropriate long-life coolant. Air filters and fuel filters require periodic inspection and replacement as per the service schedule to maintain proper air intake and fuel delivery, preventing contaminants from reaching critical engine components.
Conclusion
The Haval 4G63S4T engine represents a practical and generally reliable choice for a used vehicle buyer, especially considering its strong foundation in proven Mitsubishi engineering. Its widespread use in popular Haval and Great Wall models ensures readily available parts and experienced technicians in relevant markets. However, potential buyers of used vehicles equipped with this engine should prioritize a comprehensive service history, with particular attention to documented timing belt replacements and consistent oil changes. While not the most technologically advanced engine, its straightforward design contributes to lower repair costs. When properly maintained, the 4G63S4T offers a robust and dependable driving experience, making it a sound investment for those seeking a practical, turbocharged SUV or light truck.
