Only in its first year of production, the full-size CX-9 crossover was equipped with the 3.5-liter V6 CY-DE or Mazda MZI engine, which was assembled at the US plant between 2006 and 2007. This motor is a part of the massive Ford Cyclone Engine gasoline power unit series.
Specifications
| Production years | 2006-2007 |
| Displacement, cc | 3496 |
| Fuel system | distributed injection |
| Power output, hp | 263 |
| Torque output, Nm | 338 |
| Cylinder block | aluminum V6 |
| Block head | aluminum 24v |
| Cylinder bore, mm | 92.5 |
| Piston stroke, mm | 86.7 |
| Compression ratio | 10.8 |
| Features | DOHC |
| Hydraulic lifters | no |
| Timing drive | chain |
| Phase regulator | iVCT |
| Turbocharging | no |
| Recommended engine oil | 5W-30 |
| Engine oil capacity, liter | 5.2 |
| Fuel type | petrol |
| Euro standards | EURO 4 |
| Fuel consumption, L/100 km (for Mazda CX-9 2007) — city — highway — combined |
18.4 9.9 13.0 |
| Engine lifespan, km | ~300 000 |
| Weight, kg | 180 |
The engine was installed on:
- Mazda CX-9 I (TB) in 2006 – 2007.
Disadvantages of the Mazda CY-DE engine
The short-lived water pump is the primary issue with all Cyclone engines.
It may leak even during brief runs, allowing the antifreeze to seep into the lubricant.
Additionally, the timing chain rotates the pump, and its wedge typically necessitates costly repairs.
Other than that, this power unit has a resource of over 300,000 kilometers and is totally dependable.
Lambda probes and a catalyst burn from it, so it cannot withstand poor fuel.
