Many of the company’s well-known compact models, including the Cynos, Tercel, and Sera, were equipped with the 1.5-liter Toyota 5E-FHE gasoline engine, which was manufactured in Japan between 1990 and 1999. Evil camshafts and the ACIS intake geometry change system set this motor apart from the 5E-FE.
The engines in the E 1.5 L family are the 3E, 3E-E, 3E-TE, 5E-FE, and 5E-FHE.
The engine was mounted on:
- Toyota Cynos L40 in 1991 – 1995; Cynos L50 in 1995 – 1999;
- Toyota Sera 1 (XY10) in 1990 – 1995;
- Toyota Tercel 4 (L40) in 1991 – 1994; Tercel 5 (L50) in 1994 – 1999.
Specifications
| Production years | 1990-1999 |
| Displacement, cc | 1497 |
| Fuel system | injector |
| Power output, hp | 110 – 115 |
| Torque output, Nm | 130 – 135 |
| Cylinder block | cast iron R4 |
| Block head | aluminum 16v |
| Cylinder bore, mm | 74 |
| Piston stroke, mm | 87 |
| Compression ratio | 9.8 |
| Features | DOHC, ACIS |
| Hydraulic lifters | no |
| Timing drive | belt |
| Phase regulator | no |
| Turbocharging | no |
| Recommended engine oil | 5W-30 |
| Engine oil capacity, liter | 3.2 |
| Fuel type | petrol |
| Euro standards | EURO 2 |
| Fuel consumption, L/100 km (for Toyota Tercel 1996) — city — highway — combined |
9.5 5.8 7.2 |
| Engine lifespan, km | ~250 000 |
| Weight, kg | 120 |
Disadvantages of the 5E-FHE engine
Keep an eye on the cooling system’s condition because this engine overheats easily;
Overheating frequently results in the cylinder head gasket breaking, seals cracking, and leaks;
Contamination of the throttle and idle speed controller channel is typically the cause of floating engine speeds;
An oil burn frequently starts closer to 150,000 km due to ring or cap wear; there are no hydraulic lifters, and the valves need to be adjusted roughly every 100,000 km.
