From 2000 to 2011, the company produced the 2.0-liter Honda K20A gasoline engine, which was fitted to popular concern models like the Accord, Civic, and Stream minivan. There were an impressive number of versions and modifications of this power unit.
Honda Motor Co. Ltd. produces the K20A, a contemporary two-liter inline gasoline engine with four cylinders. Many contemporary Honda automobile models come equipped with a motor of this kind. This engine is currently the Honda brand’s most potent and ideal serial engine. Each model of this engine has a different compression ratio. The vehicle in which the engine is to be installed determines the power.
The K23A and K24A engines are also part of the K-series.
Specifications
| Production years | 2000-2011 |
| Displacement, cc | 1998 |
| Fuel system | injector |
| Power output, hp | 155 – 160 (K20A1, K20A3, K20A4, K20A6) 200 – 220 (K20A, K20A2) |
| Torque output, Nm | 180 – 190 (K20A1, K20A3, K20A4, K20A6) 190 – 215 (K20A, K20A2) |
| Cylinder block | aluminum R4 |
| Block head | aluminum 16v |
| Cylinder bore, mm | 86 |
| Piston stroke, mm | 86 |
| Compression ratio | 9.7 – 9.8 (K20A1, K20A3, K20A4, K20A6) 11.0 – 11.7 (K20A, K20A2) |
| Features | DOHC |
| Hydraulic lifters | no |
| Timing drive | chain |
| Phase regulator | i-VTEC |
| Turbocharging | no |
| Recommended engine oil | 5W-30 |
| Engine oil capacity, liter | 4.2 |
| Fuel type | petrol |
| Euro standards | EURO 3/4 |
| Fuel consumption, L/100 km (for Honda Accord 2004) — city — highway — combined |
10.3 6.2 7.7 |
| Engine lifespan, km | ~300 000 |
| Weight, kg | 150 |
The engine was installed on:
- Acura RSX 1 (DC) in 2001 – 2006;
- Honda Accord 7 (CL) in 2002 – 2008;
- Honda Accord 7 USA (CM) in 2002 – 2007;
- Honda Civic 7 (ES) in 2001 – 2005;
- Honda Civic 8 (FD) in 2005 – 2011;
- Honda CR-V 2 (RD5) in 2001 – 2006;
- Honda FR-V 1 (BE) in 2004 – 2007;
- Honda Integra 4 (DC) in 2001 – 2006;
- Honda Stepwgn 2 (RF3) in 2001 – 2005;
- Honda Stepwgn 3 (RG) in 2005 – 2009;
- Honda Stream 1 (RN) in 2000 – 2006.
Disadvantages of the Honda K20A engine
The exhaust camshaft’s rapid wear is this engine’s most well-known issue.
Unadjusted valves can also be the source of knocking under the hood.
Idle speeds frequently float here due to throttle valve contamination.
Additionally, the engine mounts are short-lived and the front crankshaft oil seal frequently leaks.
Localized overheating of the fourth cylinder plagued the engines during the initial years of production.
K20A Engine Repair Parts List
| Full name of the part | Part code |
| Piston rings Honda K20A/K20B d.86.0 STD 1.2-1.2-2.0 (13011-PNE-G02) (4 cylinder) TP | 32399-STD |
| Upper gasket set Honda K20A Payen | CG5810 |
| Head gasket | AG5810 |
| Head gasket Honda K20A (12251-PNC-003) Elring | 270.340 |
| Valve cover gasket | 270.380 |
| Valve cover gasket | HM5267 |
| Valve cap inlet Honda color code “white” (12210-P45-G01) Elring | 130.560 |
| Oil scraper cap | 130.860 |
| Valve stem seals (130.860+130.560) | 084.300 |
| Stuffing box | 81-53338-00 |
| Stuffing box 80x98x10/7.7 (614 830) Elring | 590.797 |
| Basic liners Honda Accord 2.4i 16V K24A 10.2002- (13321-PNA-003/004) Taiho | M469A-STD |
| Semi-rings persistent Honda Accord 2.4i 16V K24A 10.2002- (13331-PNA-004) Taiho | T469A-STD |
| A / C Compressor Solenoid Honda CRV 2002-> | 38924-PND-006 |
| A / C compressor pulley Honda CRV 2002-> | 38900-PNB-006 |
| Spark plug DOUBLE COPPER (RC9MCC4) Champion | OE089 /T10 |
| Spark plug MULTI-GROUND (RC8DMC) Champion | OE026/T10 |
| Oil filter Ford/Honda h=87.0 d=66.0 Champion | F126 /606 |
| V-ribbed belt 7PK1760 AE | MVB1760R7 |
| Head lamp HB3 | 091 212 115 |
| Stop light 12V 21/5W W3x16Q, four pin (for Japanese) (Osram 7515, Philips 12066) Monark | 091 612 154 |
| Stop light 12V W5W 2,1×9,5D (Osram 2825, Philips 12961) Monark | 091 712 033 |
| Mini fuses set 6 things (5A-15A) Monark | 099 837 975 |
| Complete set of Honda gaskets K20A4 (06110-PNL-E00 + 06110-PPA-000 + 06114-PNA-040) Eristic | EF6543 |
| Water pump assembled | 50005902 |
| Basic liners upper Honda K20A/K24A STD (1 half ring) (13323-RAA-A01) Original | 13323-RAA-A02 |
| Base liners, bottom Honda K20A/K24A STD (1 half ring) (13343-RAA-A01) Original | 13343-RAA-A02 |
| Connecting rod bushings Honda K20A/K24A STD (1 half ring) Original | 13213-RAD-Y01 |
| Semi-rings persistent | 13331-PNA-004 |
| Fuel filter Honda Accord 1.8i-2.2i 16V, Civic 1.5i-1.8i 16V KS | 50 013 824 |
| Upper Gasket Set Honda Civic K20A3 Payen | CG8130 |
| Lower gasket set | 06114-PND-010 |
| Valve guide | G11472 |
| Valve guide | G11513 |
| Timing kit Honda K20A6 (chain + tensioner + dampers + 2 sprockets) (14401-PNA-004) FAI | TCK189NG |
