From 1997 to 2003, the company produced the 2.3-liter Honda F23A gasoline engine, which was fitted to popular Japanese models like the Accord and the Odyssey minivan. They provided two versions of the F23A motor, one with and one without the VTEC phase control system.
Internal combustion engines F18B, F20A, F20B, F20C, and F22B are also part of the F-series.
The engine was mounted on:
- Acura CL 1 (YA) in 1997 – 1999;
- Honda Accord 6 (CG) in 1997 – 2002;
- Honda Odyssey 1 (RA) in 1994 -1999;
- Honda Odyssey 1 USA (RA) in 1994 – 1998;
- Honda Odyssey 2 (RA6) in 1999 – 2003.
Specifications
| Production years | 1997-2003 |
| Displacement, cc | 2254 |
| Fuel system | injector |
| Power output, hp | 135 (without VTEC: F23A5) 150 (with VTEC: F23A1, F23A4, F23A7) |
| Torque output, Nm | 205 |
| Cylinder block | aluminum R4 |
| Block head | aluminum 16v |
| Cylinder bore, mm | 86 |
| Piston stroke, mm | 97 |
| Compression ratio | 8.8 (without VTEC: F23A5) 9.3 (with VTEC: F23A1, F23A4, F23A7) |
| Features | SOHC |
| Hydraulic lifters | no |
| Timing drive | belt |
| Phase regulator | no (without VTEC: F23A5) VTEC (with VTEC: F23A1, F23A4, F23A7) |
| Turbocharging | no |
| Recommended engine oil | 5W-30 |
| Engine oil capacity, liter | 4.3 |
| Fuel type | petrol |
| Euro standards | EURO 3/4 |
| Fuel consumption, L/100 km (for Honda Odyssey 2000) — city — highway — combined |
13.2 8.0 9.9 |
| Engine lifespan, km | ~350 000 |
| Weight, kg | 145 |
Disadvantages of the Honda F23A engine
After 100,000 kilometers, owners of cars with this engine typically complain about oil consumption.
Complaints about frequent coolant and oil leaks rank second.
A dirty idle valve and EGR are typically the cause of tripping and floating engine speeds.
The timing belt will bend the valves if you don’t replace it after about 90,000 kilometers.
Every 40,000 kilometers, the valves must be adjusted because there are no hydraulic lifters.
F23A Engine Repair Parts List
| Full name of the part | Part code |
| Piston without rings Honda F23A5 d86.0 STD (13010-PAB-A00) Teikin | 38172 STD |
| Piston rings Honda F23A d86.0 STD 1.2–1.2–2.8 (13011-PEA-003) 4 cylinders TP | 32395-STD |
| Complete gasket set | JFS-40200 |
| Complete set of Honda gaskets F23A SOHC 16V 1995 (06110-PEA-000) Eristic | EF6341 |
| Upper Gasket Set Honda F23A, SOHC 16V 1995 Eristic | EH6341 |
| Head gasket Honda F23A SOHC 16V 1995 (12251-PAA-A010) Eristic | EG634 |
| Intake manifold gasket | 71-53792-00 |
| Valve cap inlet Honda color code “white” (12210-P45-G01) Elring | 130.560 |
| Oil scraper cap | 130.860 |
| Valve stem seals (130.860+130.560) | 084.300 |
| Water pump | 50 005 080 |
| Spark plug DOUBLE COPPER (RC9MCC4) Champion | OE089 /T10 |
| Inlet valve | 14711-PDA-E00 |
| Inlet valve | 14721-PDA-E00 |
